XFSG05 – Industrial-Grade Monolayer Graphene Powder
Precision-Engineered for Advanced Energy, Sensor, and Composite Applications
✅ Overview
XFSG05 is a high-purity, single-layer reduced graphene oxide (rGO) powder engineered for industrial applications that demand precision and performance. With a typical lateral diameter of 10–20 μm, a thickness of 1–2 nm, and an outstanding specific surface area of 633 m²/g, XFSG05 stands out in the market as a true monolayer graphene material validated by SEM, TEM, AFM, and XPS analyses.
🌟 Key Features & Benefits
-
Monolayer Structure
Verified by AFM, XFSG05 exhibits genuine single-layer graphene characteristics, ensuring higher surface activity and conductivity. -
High Surface Area
A specific surface area of 633 m²/g allows for greater interaction with electrolytes, matrices, or target molecules, boosting performance in capacitive or reactive applications. -
Excellent Purity
Composed of 98 wt% carbon, with minimal oxygen and sulfur content, XFSG05 provides reliable conductivity and chemical stability. -
Scalable & Consistent
Each batch is produced under strict quality control, ensuring batch-to-batch reproducibility for industrial use.
🔬 Technical Specifications
| Property | Value |
|---|---|
| Appearance | Black powder |
| Diameter | 10–20 μm (SEM) |
| Thickness | 1–2 nm (AFM) |
| Purity | 98 wt% (XPS) |
| Specific Surface Area | 633 m²/g (BET) |
| Main Ingredient | Reduced Graphene Oxide (rGO) |
| Elemental Composition | C: 91.06%, O: 7.18%, S: 1.76% |
⚠️ Note: Surface area and XPS data are subject to batch variation due to the nature of nanomaterial production.
🧪 Characterization Images
-
SEM: Lateral morphology confirmation
-
TEM: Transparent, wrinkle-free monolayers
-
AFM: Thickness measurement
-
XPS: Elemental composition
-
XRD: Graphitic layer analysis
(可选：如您需要，我可为这些图像配文与网页布局建议)
🚀 Application Areas
-
Electrochemical Sensors
Leverages high conductivity and surface area for signal amplification. -
Supercapacitors & Lithium-ion Batteries
Enables faster charge/discharge rates and improved capacity retention. -
Composites & Coatings
Acts as a reinforcing phase in polymers, metals, and ceramics. -
Biomedical Carriers
Promising for drug delivery and biosensing due to biocompatibility.
📦 Storage & Handling
-
Store sealed, in a cool, dry, light-proof environment.
-
Shelf life: 6 months under recommended conditions.
📞 Request a Sample / Technical Consultation
Interested in optimizing your product with XFSG05?
👉 Contact Us for data sheets, quotes, or custom specifications.
